# 233 steam launch 28′, # 237, 239, 246, 262, 270, 275

Object Number: HH.5.00028

Please note zoom and rotate functionality is temporarily unavailable.

Place Made
United States, Rhode Island, Bristol
Date Made
1909
Description
Catalog Notes: Notes for various changes for sister vessels in pencil and ink around edges; NGH appr. Mar. 19 [1903]. Related vessel name: Vixen. Related hulls: 233p, 237p, 239p, 246p, 262p, 270p, 275p. Associated HMCo plans: 2-11, 25-7, 43-37, 55-6, 66-38, 66-40, 70-2, 71-8, 71-13.
Major Collection
Nautical
Named Collection
Haffenreffer-Herreshoff Collection

More Details

Additional information
HMCo pattern number(s): 01842, 00083, 00002, 08901, 07042, 02006, 06997, 02841, 02842, 02844, 01556, 01554, 01555, 01221.5, 09734, 09733, 09732, 07034, 02757, 06977, 07035, 07030, 06967, 06966, 02804, 03173, 03174, 08448, 01542, 01298, 01299, 02339, 01546, 05706, 05661, 02108, 07329, 09405, 9405A, 01782.5, 02843, 01401, 01402, 01047,
Measurements
31 1/4" x 22 1/8"
Classification
Naval Architecture
Plan Type / View
construction
Scale
1" = 1'
Item Count
1
Credit Line
Gift of Haffenreffer Family Foundation, 1961
Cite This Item
"# 233 steam launch 28′, # 237, 239, 246, 262, 270, 275", Plan, 1909. MIT Museum, Cambridge MA. https://collections.mitmuseum.org/object/hh-5-00028/
Copyright Restrictions
Some restrictions on use. Please contact MIT Museum.
