Launch – stm, 48′ o.a., vidette boat, for English and French

Object Number: HH.5.00157.1

Please note zoom and rotate functionality is temporarily unavailable.

Place Made
United States, Rhode Island, Bristol
Date Made
1881
Description
Catalog Notes: Coaming, deck beam and hatch notations at top right corner; changes for engine bolt locations for # 85 and 86 at center of bottom edge. Related vessel names: 149, 150. Related hulls: 74p, 75p, 85p, 86p.
Major Collection
Nautical
Named Collection
Haffenreffer-Herreshoff Collection

More Details

Additional information
HMCo pattern number(s): 01990, 01989, 00072, 02006, 02097, 02094, 01998.5, 02008, 02009, 01300, 01795, 01717, 01718, 01961, 00059, 00060, 01965, 01962, 01365, 01366, 01970, 02083, 02082, 02011, 02010, 02081, 01784, 01969, 01968, 02077, 00072,
Measurements
37 1/2" x 23 7/8"
Classification
Naval Architecture
Plan Type / View
construction
Scale
3/4" = 1'
Item Count
1
Credit Line
Gift of Haffenreffer Family Foundation, 1961
Cite This Item
"Launch – stm, 48′ o.a., vidette boat, for English and French", Plan, 1881. MIT Museum, Cambridge MA. https://collections.mitmuseum.org/object/hh-5-00157-1/
Copyright Restrictions
Some restrictions on use. Please contact MIT Museum.
