Crank shaft and stanchion for 3 1/2″ x 3 1/2″ circulating engine Strs. # 191 + 192, Torpedo boats 15 + 16

Object Number: HH.5.01111

Please note zoom and rotate functionality is temporarily unavailable.

Place Made
United States, Rhode Island, Bristol
Date Made
1897
Description
Catalog Notes: "Approved Sep. 10 1897 M.A. Anderson U.S.N."; blueprint dates, notes. Related vessel names: Gwin, Talbot, TB15, TB16. Related hulls: 69p, 191p, 192p.
Major Collection
Nautical
Named Collection
Haffenreffer-Herreshoff Collection

More Details

Additional information
HMCo pattern number(s): 03474, 03465, 03466,
Measurements
21" x 16"
Classification
Marine Engineering
Plan Type / View
engine detail
Scale
Half size
Item Count
1
Credit Line
Gift of Haffenreffer Family Foundation, 1961
Cite This Item
"Crank shaft and stanchion for 3 1/2″ x 3 1/2″ circulating engine Strs. # 191 + 192, Torpedo boats 15 + 16", Plan, 1897. MIT Museum, Cambridge MA. https://collections.mitmuseum.org/object/hh-5-01111/
