26 1/2′ o.a., 21′ w.l., 7′-11″ beam, 2′-7″ dr. [sail plan]

Object Number: HH.5.08080

Please note zoom and rotate functionality is temporarily unavailable.

Place Made
United States, Rhode Island, Bristol
Date Made
1919
Description
Catalog Notes: Notes.
Major Collection
Nautical
Named Collection
Haffenreffer-Herreshoff Collection

More Details

Measurements
17" x 22"
Classification
Naval Architecture
Plan Type / View
sail
Scale
1/2" = 1'
Item Count
1
Credit Line
Gift of Haffenreffer Family Foundation, 1961
Cite This Item
"26 1/2′ o.a., 21′ w.l., 7′-11″ beam, 2′-7″ dr. [sail plan]", Plan, 1919. MIT Museum, Cambridge MA. https://collections.mitmuseum.org/object/hh-5-08080/
Copyright Restrictions
Some restrictions on use. Please contact MIT Museum.
